Gewindelehrringe zylindrisches Whitworth-Rohrgewinde

Thread ring gauges, go / no-go for cylindrical Whitworth pipe threads to DIN EN ISO 228

Thread ring gauges, go / no-go made of gauge steel for cylindrical Whitworth pipe threads to DIN EN ISO 228.

  • For fast and unambiguous tolerance inspection
  • Standard: zylindrisches Whitworth-Rohrgewinde nach DIN EN ISO 228
  • Material: Lehrenstahl
  • Choice of 24 versions
Open inquiry cart

Non-binding net prices for business customers. Data are maintained automatically; only our checked quotation or order confirmation is binding.

Item numbers from technical documents and accessory lists can be copied or entered here directly for searching.

Product description

Technology and application at a glance

Open this section for the complete technical and practical details.

Show full description Close description

Application and measuring principle

Thread ring gauges, go / no-go made of gauge steel for cylindrical Whitworth pipe threads to DIN EN ISO 228.

Gauges verify dimensions and tolerances quickly and unambiguously without requiring a numerical reading. Depending on design and standard, they provide go, no-go, setting or inspection functions.

Versions and technical selection

The main selection criteria are measuring range, resolution or scale division, measuring geometry, measuring depth and, where applicable, data output. The item variants are compared below with their technical values.

  • Standard: zylindrisches Whitworth-Rohrgewinde nach DIN EN ISO 228
  • Material: Lehrenstahl
  • Choice of 24 versions

Typical applications

Gauges are used in incoming inspection, production and final inspection when a fast and repeatable go/no-go decision is required. Nominal size, tolerance field, thread type and standard must match the drawing completely.

Advice, calibration and service

Ballbach assists with selecting the suitable version, assigning accessories and assessing the metrological requirements. A suitable factory calibration can be supplied together with the instrument. DAkkS calibration is available on request where the measurand and version are within the accredited scope.

Article variants

Select the suitable version

Ballbach item no. Thread size Version Net price Details Inquiry
2745001 G 1/16 Gut oder Ausschuss bei Bestellung angeben Price on request
2745006 G 5/8 Gut oder Ausschuss bei Bestellung angeben Price on request
2745002 G 1/8 Gut oder Ausschuss bei Bestellung angeben Price on request
2745007 G 3/4 Gut oder Ausschuss bei Bestellung angeben Price on request
2745003 G 1/4 Gut oder Ausschuss bei Bestellung angeben Price on request
2745008 G 7/8 Gut oder Ausschuss bei Bestellung angeben Price on request
2745004 G 3/8 Gut oder Ausschuss bei Bestellung angeben Price on request
2745009 G1 Gut oder Ausschuss bei Bestellung angeben Price on request
2745005 G 1/2 Gut oder Ausschuss bei Bestellung angeben Price on request
2745010 G 1 1/8 Gut oder Ausschuss bei Bestellung angeben Price on request
2745011 G 1 1/4 Gut oder Ausschuss bei Bestellung angeben Price on request
2745018 G3 Gut oder Ausschuss bei Bestellung angeben Price on request
2745012 G 1 1/2 Gut oder Ausschuss bei Bestellung angeben Price on request
2745019 G 3 1/2 Gut oder Ausschuss bei Bestellung angeben Price on request
2745013 G 1 3/4 Gut oder Ausschuss bei Bestellung angeben Price on request
2745020 G4 Gut oder Ausschuss bei Bestellung angeben Price on request
2745014 G2 Gut oder Ausschuss bei Bestellung angeben Price on request
2745021 G 4 1/2 Gut oder Ausschuss bei Bestellung angeben Price on request
2745015 G 2 1/4 Gut oder Ausschuss bei Bestellung angeben Price on request
2745022 G5 Gut oder Ausschuss bei Bestellung angeben Price on request
2745016 G 2 1/2 Gut oder Ausschuss bei Bestellung angeben Price on request
2745023 G 5 1/2 Gut oder Ausschuss bei Bestellung angeben Price on request
2745017 G 2 3/4 Gut oder Ausschuss bei Bestellung angeben Price on request
2745024 G6 Gut oder Ausschuss bei Bestellung angeben Price on request
